SPL Track One Mk3 Model 2240

SPL Track One Mk3 Model 2240

Compact and Versatile Channel Strip

Overview: The SPL Track One Mk3 is a renowned compact channel strip widely used in broadcast, voice recording, singer-songwriter production, live events, and podcasts. This high-quality recording and mixing channel strip has been further refined in the Mk3 version, offering an even more intuitive and sophisticated design, ideal for modern recording studios.

Key Features:

• Two Preamplifiers: Includes a microphone preamp with 48V phantom power and an instrument preamp, both designed for neutral, open, and transparent sound.
• Adjustable Gain: Up to 63 dB for microphones, with a range for line signals of -12 dB to +22 dB and 0 dB to +35 dB for instrument signals.
• Analog Plugin Capability: Allows processing of line signals with de-esser, compressor, limiter, and equalizer for re-recording.
• 48V Phantom Power: For use with condenser microphones.
• Highpass Filter: Reduces low-frequency noise below 80 Hz.
• Auto-Dynamic De-Esser: Provides unobtrusive and effective sibilance reduction.
• Compressor/Limiter: Features an easy-to-use design with excellent noise and distortion specifications.
• Integrated Equalizer: Includes LMF and MHF filters for full-spectrum coverage, plus an AIR filter for high frequencies.
• Compressor Link Feature: Allows stereo operation of two Track One compressors.
• Optional Lundahl Transformers: Enhance bass and fundamental tones while providing silkier high frequencies.

Technical Specifications:

• Inputs/Output: XLR & TRS Jack (balanced, except INSTR./LINE IN: unbalanced)
• Max Input Gain (Mic/Line/Instrument): 10.6 dBu/33.5 dBu/21.5 dBu
• Input Impedance (Mic/Line/Instrument): 10 kΩ/47 kΩ/1.1 MΩ
• Max Output Gain: 20 dBu
• Frequency Range (Mic): 10 Hz – 195 kHz
• Dynamic Range: 130.5 dB
• Internal Power Supply: +/- 15 V, 48 V Phantom
• Mains Voltage: Selectable 230 V AC / 50; 115 V AC / 60 Hz

Applications: The SPL Track One Mk3 is perfect for achieving professional results in various audio applications. Its comprehensive features and compact design make it ideal for studios and live environments where space is limited but quality cannot be compromised.
