SPL Big The Stereo Image Bigger Maker for series 500
Transform your audio with BiG, the revolutionary 500 Series double-slot module, designed to expand and enhance stereo imaging in an unprecedented way. With its intuitive three-control interface, BiG offers a new creative dimension in sound shaping, making it a must-have tool for audio professionals.
Key Features:
- Simplified Control: Effortlessly switch between the processed and unprocessed signal with the On/Bypass switch.
- Signal Indicators: Signal LEDs indicate audio presence at the input of each channel for efficient monitoring.
- Stereo Image Shaping: Customize your sound with the Range control to select the frequency range, and the Stage control to position it within the stereo field.
- BIGNESS Control: Adjust the intensity of the stereo image shaping to achieve the desired spatial effect.
- Bass Boost Option: Activate additional bass boost with the BASS/Off switch for enhanced low-end richness, using a circuit similar to SPL’s IRON Mastering Compressor.
Technical Specifications:
- Input & Output: Balanced
- Maximum Input & Output Gain: 21 dBu
- Input Impedance: 20 kΩ
- Output Impedance: 150 Ω
- Common Mode Rejection: > 82 dB
- Frequency Range: 10 Hz – 100 kHz (-3 dB)
- THD & N: 0.03% (0 dBu, 10 Hz – 22 kHz)
- Noise: -92.3 dBu (A-weighted)
- Dynamic Range: 113 dB
- Dimensions: Double-spaced module for 500 Series
- Unit Weight: 0.9 kg
- Short Description:
- The Stereo Image Bigger Maker for series 500
- Bundled:
- No
- california pro_65:
- No
- Connectivity:
- TRS 1/4;XLR
- Effect/Enhancement:
- Enhancer
- Features:
- Solid State
- Form Factor:
- 500
- Model:
- 1505
- Number of Channels:
- 2
- Type (Signal Processors):
- 500 Rack;Deesser
- SKU:
- SPL-BIG
